MOBILE SATELLITE ANTENNAS

VEHICLE MOUNTED MOBILE SATELLITE ANTENNAS

Kymeta u7 Terminal

Kymeta Ku-Band satellite terminals address the need for lightweight, slim, and high-throughput communication systems that do not require mechanical components to steer toward a satellite and make connecting nearly any vehicle, vessel, or fixed platform easy.

KYMETA SATELLITE TERMINALS FEATURE:
  • Flat-panel for low-profile installation options
  • Electronic steering for low maintenance and reliable connectivity
  • Simple power-on startup and auto-acquisition for easy operation
  • Broad applicability–for vessels and vehicles
  • Reliable communications even at high speeds and on rough seas or terrain
  • Low power consumption and requirements

Cobham EXPLORER 8100

The unique Dynamic Pointing Correction technology and an advanced carbon fiber reflector make the 1 meter EXPLORER 8100 the most advanced Auto-Acquire Drive-Away Land VSAT antenna available in its class.

KEY FEATURES FOR COBHAM EXPLORER 8100:
  • Genuine EXPLORER Design
  • Single Piece 1.0m Offset Feed Carbon Fiber Reflector for Multi-Band Ku/Ka Operation
  • Built-in Wifi and a Web-based User Interface for easy PC and Smartphone Configuration
  • Precision Polarization Drive in Ku-band configuration
  • Dynamic Pointing Correction and inclined orbit satellite tracking
  •  Available in an 8W BUC, 20W BUC, and a no BUC option

Cobham EXPLORER 8120

EXPLORER 8120 features industry-leading fast satellite acquisition with pointing achieved in less than four minutes, making getting connected to a satellite a quick and easy process. The system is available in Ku-band configuration and works with most major satellite networks.

KEY FEATURES FOR COBHAM EXPLORER 8120:
  • Genuine EXPLORER Design
  • Rugged, Reliable 1.2m Auto-Acquire Drive-Away Antenna
  • Single Piece 1.2m Offset Feed Carbon Fiber Reflector for exceptional performance
  • Built-in Wifi and a Web-based User Interface for easy PC and Smartphone Configuration
  • Precision Polarization Drive
  • Harmonic Drive Gear systems
  • Dynamic Pointing Correction technology and inclined orbit satellite tracking
  • Available in an 8W BUC, 20W BUC, and a no BUC option

Ground Control TOUGHSAT XP Series

1.2 & .98 METER OPTIONS

Ground Control TOUGHSAT XP Series Mobile Satellite Systems are designed for rugged reliability in the most challenging of environments. Quick one-button deployment provides high-speed Internet & phone connectivity in less than 3.5 minutes…Everywhere.

KEY FEATURES FOR GROUND CONTROL TOUGHSAT XP SERIES:
  • One-button operation
  • Requires little or no training to operate
  • Dish peaking accuracy is within 0.1 degrees with near zero play
  • Establishes a self-contained local area network with one button
  • Establishes a wireless access point and wiring to computers is optional
  • System is not affected by magnetic distortions to lock on any satellite
  • Operates globally in both hemispheres

AvL 1078

Offset 1.0m composite reflector and AvL Cable Drive positioner for reliability and ease of operation. The compact, low-profile and cost-effective motorized antenna allows for use on smaller vehicles such as an SUV or van, and includes a versatile vehicle-mount pallet.

KEY FEATURES FOR AVL MODEL 1078:
  • Zero Backlash AvL Cable Drive
  • Optional Transmit Rotary Joint on Feed
  • Stows to 15″ H (38.1 cm H)
  • Can be mounted onto large SUV or van
  • Versatile vehicle-mount pallet with optional Thule bar interface
  • Standard 2-Port Ku Precision (standard Cross-Pol comp.) Feed

AvL 1258

1.2m Low-Stow Vehicle-Mount / DriveAway Mobile VSAT antenna features an offset 1.2m core-free carbon fiber reflector paired with a patent-pending AvL Cable Drive positioner. The antenna can be mounted on a large SUV, van, or larger vehicles and trailers.

KEY FEATURES FOR AVL MODEL 1258:
  • Zero Backlash AvL Cable Drive
  • Optional Transmit Rotary Joint on Feed
  • Stows to 15″ H (38.1 cm H)
  • Can be mounted onto large SUV or van
  • Standard 2-Port Ku-Band Precision (standard Cross-Pol comp.) Feed
  • Embedded one button auto-acquisition ACU with IRU P/S
  • Integrated GPS
  • Level sensors for auto vehicle tilt compensation and auto cross pol alignment

AvL 1278

Reliable, robust and simple to operate, the 1.2m Vehicle-Mount / DriveAway Mobile VSAT antennas feature an offset 1.2m reflector paired with a patent-pending AvL Cable Drive positioner. Can be mounted on a large SUV, van, or larger vehicles and trailers.

KEY FEATURES FOR AVL MODEL 1278:
  • 1.2m AvL Engineered Composite Reflector
  • Zero Backlash AvL Cable Drive
  • Optional Transmit Rotary Joint on Feed
  • Stows to 18.4″ H (46.7 cm H)
  • Can be mounted onto large SUV or van
  • Standard 2-Port Ku Precision (standard Cross-Pol comp.) Feed
  • One button auto-acquisition controller
Looking for more information on our Mobile Solutions? Contact us today.
